Daikin air conditioner symbols appear on both the remote and the indoor unit, and most are easy to decode. The screen on a Daikin controller is dense. Small pictures crowd the edges, a couple of them appear only occasionally, and none of them come with a caption telling you what has just changed.
Daikin air conditioner symbols are worth learning because several of them are not settings at all. Some tell you the system is protecting itself, some tell you another device is in charge, and one tells you the clock has lost its place and every timer you set is now running at the wrong hour.
This guide covers the symbols on both handheld remotes and wall mounted Daikin controllers, what each one actually means, and which ones need action from you rather than a phone call.
The chart below covers the symbols you are most likely to meet, on both the handheld remote and the wall controller. Everything after it explains the same symbols in more detail.
Daikin air conditioner symbols at a glance
If your system is a different brand, our general guide to air conditioner symbols covers the ones every manufacturer shares.
| Symbol | What it means | What to do |
|---|---|---|
| Snowflake | Cooling mode. | Use it in summer. If the air is not cold, check the set temperature and the filters first. |
| Sun | Heating mode. | Use it in winter. Warm air is held back until the indoor coil warms up. |
| Water drop | Dry mode, which removes humidity rather than chasing a temperature. | Use it on a humid but mild day. Slow airflow here is normal. |
| Fan | Fan only, with no cooling or heating. | Useful on a mild day at very low running cost. |
| AUTO | The unit chooses cooling or heating for you. | Fine in settled weather. On a mild day it can pick the mode you did not want. |
| Airflow rate bars | Fan speed, including an automatic setting. | Leave it on auto unless you want the unit quieter. |
| Airflow direction arrow | Which way the flap is steering the air. | Aim air across the room rather than down onto a seat. |
| Filter icon | Time to clean the filter. Maintenance, not a fault. | Clean the filter, then reset the indicator or the icon stays on. |
| Key or padlock | The controller keys are locked. | On a wired controller, hold the menu and enter button for four seconds to release it. |
| Clock, or ON and OFF | A timer is set, or the clock needs setting again after a power interruption. | If the unit refuses to start, cancel every timer, then set the clock. |
| Defrost | The outdoor unit is clearing ice during heating. | Nothing. Warm air returns when the cycle ends. |
| Centralised control | The system is under central control and local changes are blocked. | Common in offices and apartments. Ask whoever manages the building. |
| Battery outline | The remote batteries are running low. | Fit two fresh AAA alkaline batteries at once, then set the clock again. |
Daikin splits its controls across a handheld remote on wall mounted splits and a wired wall controller on ducted systems. The wall controller shows words as well as symbols, so if a symbol has you stuck on a ducted system, the controller menu usually names it.
Two kinds of Daikin display, two slightly different symbol sets
Before reading any chart, work out which controller you are holding, because the symbol sets overlap but are not identical.
- A handheld infrared remote comes with most wall mounted split systems and has a small screen with the basics on it.
- A wall mounted controller is wired in, usually on ducted and cassette systems, and carries far more information.
- Touchscreen controllers show short words alongside the symbols, which makes them the easiest of the three to read.
The wired controllers are where the less obvious symbols live, because they report on things a handheld remote never needs to mention.
Daikin aircon symbols for operating mode
Mode is the setting that decides everything else, and Daikin displays it as a symbol rather than a word on most controllers.
- A snowflake is cool. Heat is removed from the room and rejected outside.
- A sun is heat. Heat is drawn in from outside air and delivered to the room.
- A water drop is dry. The system removes humidity rather than chasing a temperature.
- A fan is fan only. Air circulates and nothing is heated or cooled.
- Auto lets the unit choose between heating and cooling for you.
- Vent appears on systems with ventilation capability and moves outside air rather than conditioning room air.
Fan and vent are the two most often selected by accident. In both cases the unit runs, air moves, and the room temperature does not change, which is easy to mistake for a fault.
If a room is not cooling and the system seems to be working, check this symbol before anything else. It resolves a surprising share of service calls.
The airflow rate symbol
Daikin shows the airflow rate set for the indoor unit as its own symbol, usually a set of bars or a small fan that fills as the speed increases.
Auto is the sensible default. It runs hard while the room is far from your setting, then eases back, which is quieter and cheaper than holding a high speed all afternoon.
A system left on its lowest airflow rate feels weak and slow, and it is one of the more common reasons someone decides their air conditioner has lost its performance.
The airflow direction symbol
This one appears when airflow direction swings are set. On most Daikin controllers it is a small louvre with an arc or arrow showing movement.
There is a simple physical rule worth knowing. Cool air sinks and warm air rises, so cooling works best with the louvres angled high and heating works best with them pointed toward the floor.
If a room heats at the ceiling and stays cold at your feet, the airflow direction symbol is the first thing to check. It is free to change and it often fixes the complaint entirely.
Set temperature and the setback symbol
The set temperature appears whenever the air conditioner is turned on, which is the one symbol nobody has trouble with.
Setback is different and far less familiar. Daikin displays a setback symbol when the air conditioner is running under setback control, which holds a room within a wider temperature band rather than at a fixed point.
Setback is common in commercial settings and in systems configured to hold a building within limits overnight. If you see it at home and did not set it, it is worth asking whoever commissioned the system.
Defrost and hot start
Daikin shows a defrost and hot start symbol when that operation is active, and it explains a complaint that comes up every winter.
In heating, ice forms on the outdoor coil. The system periodically reverses to melt it, and while that happens the indoor unit stops delivering warm air. Hot start is the related behaviour of holding the indoor fan back until the coil is warm, so you are not blasted with cold air at the beginning of a heating cycle.
Both are protective and both end on their own. A system that pauses its warm air in the middle of a cold morning is usually doing this rather than failing.
Quick start on split systems
Daikin displays a quick start symbol when the quick cooling or heating function is turned on, and this one applies to split systems.
It is a burst setting for shifting a room fast rather than a way to run the system all day. Left on, it is noisier and it costs more.
If your unit is running harder than usual for no reason you can identify, check whether this symbol is showing.
The filter cleaning symbol
Daikin wired controllers show a message when the filter needs cleaning, and ducted or cassette systems with a wireless receiver light a filter lamp, but wall split handheld remotes have no filter sign.
Two things are worth knowing about it. First, it is driven by running hours rather than by anything the system measures, so it appears on schedule whether the filters are dirty or not. Second, it does not clear itself, so it will stay on the screen after you have cleaned them until you reset it.
- Switch the unit off before opening the indoor unit.
- Slide the filters out and wash them in lukewarm water.
- Let them dry completely before refitting, because a damp filter feeds mould growth.
- Refit the filters and close the panel.
- Reset the filter indication from the controller so the counter starts again.
Filters are the single cheapest thing you can do for a Daikin, and they prevent a family of faults that look far more serious than they are.
Ventilation and air purifying symbols
These two only appear on systems that have the matching equipment fitted, which is why most homeowners never see them.
- A ventilation symbol is displayed when a heat reclaim ventilator is connected to the system.
- An air purifying symbol indicates that an air purifying unit, which is an optional accessory, is operating.
If either appears on your controller and you did not know your system had that equipment, it is worth checking the original installation paperwork. They are not fault indications.
The key lock symbol
A padlock or key symbol indicates that the key lock is set. It is the reason a controller can appear completely dead while the system carries on running.
Key lock is common in offices, rentals and shared spaces, where it stops the settings being changed by whoever walks past. Daikin handheld remotes for wall splits do not have a key lock, so this symbol only appears on wired wall controllers.
If your buttons do nothing but the screen is lit, look for this symbol before assuming the controller has failed.
The Daikin eye, a symbol that is just a colour
Some Daikin wall mounted models replace the row of indicator lamps with a single illuminated strip that Daikin calls the Daikin eye. It carries no icon at all. The colour is the message.
Worth being precise about where this applies. Daikin publishes the colour meanings in its European documentation for the Stylish range. The Australian Zena manual calls this the multi-monitor lamp and gives the same colour meanings, while the separate green lamp is the intelligent eye, which is a motion sensor rather than a status indicator. If your unit has a single coloured strip, the list below is what Daikin says it means.
- Blue means cooling.
- Red means heating.
- Red and blue together means automatic mode.
- Green means drying.
- White means fan only.
- Orange means a timer is running.
That white one catches people out. A white Daikin eye is not a fault light. It means the system is moving air and neither cooling nor heating it, which is exactly why the room is not getting any cooler.
Daikin also notes that when an off and on timer or a weekly timer is set, the eye turns orange for about ten seconds, then returns to the colour of the operating mode for three minutes.
If your Daikin has a row of separate lamps rather than one coloured strip, this section does not apply to you. Read the operation lamp and the timer lamp instead, which are covered further down.
Daikin timer symbols and the clock warning
Timer symbols are among the most useful to understand, because they explain most cases of a system that refuses to start when you want it.
- A timer symbol is displayed to indicate that a schedule timer or an off timer is enabled.
- A separate symbol is displayed when the clock needs to be reset.
That second one matters more than it looks. If the clock has lost its setting, usually after a power interruption, every timer on the system is now running at the wrong hour. A schedule that made sense yesterday can leave a building cold this morning.
Set the clock first, then check the schedule. Resetting timers without fixing the clock simply moves the problem.
Centralised control and changeover symbols
These two say the same thing in different ways. Something other than the controller in front of you is making the decisions.
- A centralised control symbol is displayed if the system is managed by centralised control equipment.
- A changeover under control symbol appears where the remote controller has no cool and heat selection eligibility, which applies to larger systems.
If you are pressing buttons and nothing changes, and one of these symbols is showing, the controller is not broken. It has been told it does not have the final say.
In a home this usually points at a building management system, a landlord configured setup, or a multi unit system where one controller is the master.
Reading the Daikin remote itself
A few things about the handheld remote are worth knowing, because they explain symbols that appear for reasons that have nothing to do with the air conditioner.
Daikin publishes two AAA alkaline batteries, fitted both at once, with a standard replacement time of about a year. A battery icon blinks as the warning. Worth knowing, Daikin notes that signal reception can start to decline before that warning ever appears, so a remote that works up close and not from across the room is often an early battery problem rather than a fault.
There is no reset button on a Daikin handheld remote. Plenty of guides tell you to press one, and Daikin does not publish one in any manual for the Australian range. The button people mistake for it is cancel, which Daikin describes as diagnosing faults and taking you back to the default screen.
The beep pattern is a symbol of sorts too, and Daikin publishes it. Two short beeps mean operation started, a single beep means a setting changed, and one long beep means operation stopped. No beep at all means the unit did not receive the signal.
Transmission distance is about 7 metres on most models and about 6 metres on the slimline range. Daikin names four things that interfere with it, a curtain or anything else blocking the path, direct sunlight falling on the transmitter, electronic fluorescent lamps in the room, and dust on either the transmitter or the receiver. That last one takes a soft cloth and five seconds.
Common questions about Daikin air conditioner symbols
What does the snowflake mean on a Daikin air conditioner?
The snowflake is cooling mode. The system takes heat out of the room and rejects it outside until the room reaches your set temperature.
If the snowflake is showing and the air is not cold, the usual causes are a set temperature above room temperature, blocked filters, or the system still sitting inside its restart delay. Daikin holds the compressor off for three minutes after a stop or a mode change.
What does the water drop symbol mean on a Daikin?
The water drop is dry mode. It removes humidity from the room and runs the fan at low speed while doing it, so weak airflow in this mode is expected rather than a fault.
Dry mode suits a humid but mild day. On a genuinely hot afternoon, cooling mode will do far more.
Why is my Daikin showing a symbol I cannot find in the manual?
Daikin uses several controller generations, and the symbol set depends on which controller you have rather than on the brand alone. A chart written for a wired controller will not match a handheld remote, and a guide for a large system will show symbols a home split system never displays.
The definitive source is the manual for your exact controller model, not for the air conditioner. The controller model number is usually printed on the back of a handheld remote or on the underside of a wall mounted one.
Other brands lay their displays out differently again. Our guide to Mitsubishi air conditioner symbols covers a remote with a very different set of extra functions.
Which Daikin air conditioner symbols mean something is wrong?
Most symbols on a Daikin are settings or status messages. Very few are warnings, which is worth knowing before you worry about any of them.
- Settings you chose include mode, airflow rate, airflow direction, set temperature, quick start and timers.
- Status messages include defrost, hot start, ventilation, air purifying, key lock, centralised control and changeover.
- Maintenance you can handle yourself is the filter cleaning indication.
- A clock reset warning needs action but is not a fault.
- A fault is usually shown as a two character code alongside a spanner or warning symbol.
Only that last group needs a technician. If your controller is showing a letter and number pairing, our guide to Daikin error codes and what they mean explains how the codes are structured and what the common ones point at.
Is there a reset button on a Daikin remote?
No. Daikin publishes no reset button on the handheld wireless remote anywhere in the Australian range. If a page tells you to press one, it is not describing a Daikin.
What Daikin does publish, for a unit that has stopped with the operation lamp blinking, is to turn the power off at the circuit breaker and restart from the remote. If the lamp is still blinking after that, the instruction is to check the error code and consult your dealer.
How do I clear the filter symbol on a Daikin?
Cleaning the filter does not clear the message on its own. The count has to be reset.
On a wired controller, open the menu and select the option to reset the filter indicator. On a wireless remote for a ducted or cassette system, Daikin asks you to press the filter sign reset button after refitting the filter, and the lamp on the receiver goes out.
Wall mounted splits do not have this at all. Daikin publishes no filter indicator on them, and recommends cleaning the filters every two weeks instead.
How do I read a Daikin error code myself?
Daikin is one of the few brands that lets an owner do this. Hold the cancel button for about five seconds, and a code blinks in the temperature display. Press cancel repeatedly to step through the codes until you hear a long beep, which marks the stored one.
Write it down before you call anyone. Our guide to Daikin error codes covers what the families mean.
Reading the display when nothing seems to be happening
When a Daikin appears to be doing nothing, the display almost always contains the answer. Work through it in order rather than guessing.
- Check the mode symbol, since fan and vent move air without changing temperature.
- Check the set temperature against how the room actually feels.
- Check the airflow rate, because the lowest setting feels like a failing system.
- Check for a timer symbol or a clock reset warning.
- Check for a key lock symbol if the buttons are not responding.
- Check for centralised control if the settings will not hold.
- Check the filter indication, then check the filters themselves.
Seven checks, none of which need a tool, and between them they cover the large majority of calls that end without a part being fitted.
When the symbols are fine and the system still is not
Sometimes the display reads perfectly and the room still will not behave. The causes are usually physical.
- Filters blocked enough to starve the indoor coil of air.
- An outdoor unit hemmed in by plants, fencing or stored items so it cannot reject heat.
- Doors and windows open onto space the system was never sized to handle.
- A refrigerant charge that has fallen, which shows as gradually weaker performance over weeks.
The first two are yours to fix and cost nothing. Our guide to how often you should service your air conditioner covers what a proper service actually includes. For the symbols every brand shares, our guide to air conditioner symbols covers the universal set.
Getting more out of your controller
Nearly every Daikin air conditioner symbol belongs to one of four groups. A mode, an airflow setting, a timer or clock message, or a status note telling you what the system or another controller is doing.
Learning the mode symbols and the timer symbols does most of the work, because between them they explain almost every occasion when a system appears to ignore you.
If the display reads correctly, the filters are clean, and the system still will not perform, the next step needs test equipment. We service Daikin split, multi head and ducted systems across Melbourne, and the price is confirmed with you before any work starts.
If the unit is behaving oddly as well as showing something unfamiliar, it is worth knowing the signs a Daikin needs servicing without waiting.
For your model’s manual and warranty details, see the official Daikin Australia website.
