The Panasonic air conditioner remote looks busy, but most people only need a few buttons. A Panasonic remote packs more named functions onto fewer buttons than almost anything else sold here. nanoe X, ECONAVI, iAUTO X, POWERFUL, QUIET and ECO all live on a handset with about ten buttons, which is only possible because several of them share.
Once you know which buttons are doubled up, the whole layout makes sense, and a few rules that look arbitrary turn out to be unavoidable. This guide works through the Panasonic air conditioner remote using the operating instructions published for the Australian range.
The buttons that share a home
Start here, because it explains two things people find confusing.
The published button list on the Australian range is off and on, mode, temperature up and down, air swing, fan speed and quiet on one button, powerful and eco on another, sleep, timer, set, and cancel.
Fan speed and quiet share a button. That is why Panasonic states you cannot select quiet and a manual fan speed at the same time. It is not a software restriction, it is one button.
Powerful and eco share a button too, which is why they behave as opposites rather than as settings you can stack.
Setting the clock, and switching to 24 hour time
The clock procedure is short and it is consistent across five Australian manuals.
- Press the clock button.
- Use the arrow buttons to set the time.
- Press SET to confirm.
The part worth knowing is the toggle. Press and hold the clock button for approximately 5 seconds to switch the display between 12 hour time with am and pm and 24 hour time. That is one of the most searched things about these remotes and it takes five seconds.
On a ducted Panasonic the clock lives in the wall controller instead. Open the menu, select clock, set the date and time with the up and down buttons and confirm. The 12 and 24 hour choice is a separate menu item named clock type.
The Panasonic timers
Panasonic publishes two sets of on and off timers, so you can turn the unit on or off at two different preset times.
To set one, select timer on or timer off, set the time, then confirm with SET. To cancel, press on or off to select the setting you want gone, then press CANCEL.
There is one behaviour here that differs from other brands and catches people out. Once set, a Panasonic timer repeats daily. It is not a one off. If the unit keeps starting itself at the same time every afternoon, an old timer setting is the first thing to look for.
Ducted systems work differently again. The wired controllers support a weekly schedule with up to eight settings for each day, and on one of them the on and off timer can be set as far out as 72 hours in 30 minute increments.
If the timer indicator on the indoor unit is blinking rather than lit, that is a fault report rather than a schedule, and our guide on a Panasonic timer light flashing covers it.
Choosing a mode
On the premium Z series the mode button cycles auto, heat, cool, iAUTO X, dry, then fan. Two separate Z series manuals publish that order including iAUTO X sitting between cool and dry.
The standard RZ series orders its modes differently and does not include iAUTO X at all. If you are counting presses from a guide written for another range you will land in the wrong place, so count them once on your own remote and remember the position.
If a symbol rather than a button has you stuck, our guide to Panasonic air conditioner symbols covers the display.
The temperature range Panasonic publishes
Panasonic is unusual here and it is worth understanding, because the wall split and the ducted controller do not agree.
| Where | Cooling and dry | Heating | Auto |
|---|---|---|---|
| Wall mounted split | 16.0 to 30.0 degrees | 16.0 to 30.0 degrees | 16.0 to 30.0 degrees |
| Ducted wired controller | 18.0 to 30.0 degrees | 16.0 to 30.0 degrees | 17.0 to 27.0 degrees |
Two things stand out. On a wall split Panasonic publishes one range of 16 to 30 degrees for auto, cool, heat and dry, while fan mode has no temperature setting at all. And the auto range on a ducted system is much narrower at 17 to 27, which surprises people who try to set 16 in auto and cannot.
Panasonic also publishes recommended settings that are not the same as the limits. It suggests 20 to 24 degrees for heating and 26 to 28 for cooling as the efficient band. Those are running cost advice, not restrictions.
Fan speed and quiet
Being straight about a gap here. Panasonic does not publish a named list of fan speed steps for its Australian wall mounted remotes. The manuals show the setting as bars on the display and never enumerate them, so any specific count you read elsewhere did not come from Panasonic.
What is published is that when fan auto is selected, the fan speed is adjusted automatically according to the operation mode.
On the ducted wired controllers the levels are named, and there are four. Auto, low, medium and high, with auto unavailable in fan mode.
Quiet is a separate thing from the lowest fan speed. Panasonic describes it as reducing airflow noise, and in its own product wording the fan speed drops to minimum while it runs.
Air swing, and the flap you must not move by hand
This section matters more than it sounds, because getting it wrong can damage the unit.
Panasonic instructs owners plainly not to adjust the vertical flap by hand. It is motorised, and it is set from the remote.
The lateral vanes are the opposite. On the models that have them, Panasonic states they are manually adjustable, so you move those by hand rather than hunting for a button.
Which you have depends on the model. The smaller units in the standard range publish upper direction only. The larger units publish both upper and lateral.
There is one more published behaviour worth knowing. The horizontal flap swings up and down automatically in cooling and drying, and is held in a fixed position in heating. That is deliberate, because warm air needs to be pushed down rather than swung around.
The named Panasonic functions
Powerful
Reaches the set temperature quickly, and stops automatically after 20 minutes. Four Australian manuals publish the same duration. Panasonic describes it as running both the compressor and the indoor fan at super high speed.
Quiet
Reduces airflow noise. Remember it shares a button with fan speed, so the two cannot both be active.
Eco
Reduces power consumption for better energy saving without sacrificing comfort, in Panasonic own wording. On the Z series it cannot be activated during iAUTO X mode.
ECONAVI
A sensor function with published numbers, which is rare. On a wall split, ECONAVI saves power in an unoccupied room by adjusting the set temperature automatically by up to 3 degrees, and dims the brightness of all indicators while it does.
On the ducted wired controller the behaviour is published in more detail. High activity in the room maintains the set temperature, low activity adjusts it by one degree, and more than 20 minutes unoccupied adjusts it by two degrees.
nanoe X
Panasonic describes this on a wall split as providing cleaner air, moisturising your skin and hair, and deodorising odours in the room.
The ducted controller describes the same technology differently, as generating negative ions to reduce smells and constrain the propagation of mould and bacteria. Same system, two different emphases.
iAUTO X
Worth being precise about this one, because it is a mode rather than a button, and it appears on the Z series only.
When it is running, the unit automatically reduces the temperature by 2 degrees below your setting to accelerate cooling. After a maximum of four hours it returns to the last set temperature on its own.
So the room deliberately overshoots, and then the setting comes back. That is the design, not a fault.
Sleep
Provides a comfortable environment while sleeping by adjusting the temperature through the night. It runs on a built in timer with ten steps, from half an hour through to nine hours.
AEROWINGS is hardware, not a button
You will see AEROWINGS in Panasonic advertising and then fail to find it on the remote. That is because it is not a button and it does not appear in any of the operating manuals.
AEROWINGS is Panasonic name for the twin flap design on some ranges, using a sub flap and an outer flap. Panasonic publishes airflow reaching up to 15 metres on the current design, with two named behaviours. Fast cooling directs concentrated airflow downwards to cool you rapidly, and shower cooling sends air across the room from above before letting it fall gently, so you are not sitting in a draught.
You control it through the normal air swing settings. There is nothing separate to press.
Running the unit without the remote
Panasonic puts an auto off and on button on the indoor unit, reached by raising the front panel. All four current Australian manuals publish the same sequence.
- Press once to run in auto mode.
- Press and hold until you hear 1 beep, then release, to run in forced cool mode.
- Press and hold until you hear 2 beeps, then release, to run in forced heat mode.
- Press again to turn the unit off.
Forced cool and forced heat do what the names suggest. They ignore the thermostat, so the unit will keep going rather than stopping at a temperature. Use auto if you simply need the system running while a replacement remote arrives.
If the remote has stopped working rather than gone missing, our guide on a Panasonic remote not working covers the reset button and the batteries.
If your Panasonic is ducted, the wall controller is the manual
Ducted Panasonic systems are run from a wired wall controller rather than a handheld, and it carries several things the handheld does not.
Scheduling is the main one. Where a wall split gives you two repeating timers, the wired controllers give you a weekly schedule with up to eight settings for each day, and each setting can turn the unit on, turn it off, turn it on at a particular temperature, or change only the temperature.
Temperature moves in different steps depending on which controller you have. One of the current controllers adjusts in half degree steps and the other in whole degrees, which is worth knowing before you conclude yours is faulty for skipping a number.
There are also settings with no equivalent on a handheld. An outing function holds the room inside a temperature band while nobody is home, starting the unit one degree inside the limit and stopping two degrees past it. A quiet operation setting reduces outdoor unit noise during nominated periods, and on one controller it is password protected because it is intended to be set once at installation. And the touch sound that confirms each button press can be switched off through the menu, which is worth doing if the controller is outside a bedroom.
nanoe X is a menu item rather than a button on these controllers, switched on and off through the settings rather than from a dedicated key.
Where to keep the remote
Panasonic supplies a holder as an accessory with mounting screws. It does not publish a step by step mounting procedure, so the practical rule is the signal range.
The published range is 8 metres from the receiver on the indoor unit. Put the holder well inside that rather than on the far wall of an open plan room, and somewhere the remote is not going to be knocked into a sink or a drink, since water damage is the one failure no reset will fix.
The remote also carries its own model number, printed on the back or inside the battery compartment. It is not the same as the air conditioner model, and it is what you quote when ordering a replacement.
Common questions about using a Panasonic remote
How do I change my Panasonic remote to 24 hour time?
Press and hold the clock button for about 5 seconds. The display toggles between 12 hour with am and pm and 24 hour.
How far does the remote work from?
Panasonic publishes 8 metres from the remote control receiver on the indoor unit, across four Australian manuals. That is further than most brands.
Why does my Panasonic turn itself on every day?
Because Panasonic timers repeat daily once set. Select the on timer and cancel it rather than assuming it will expire.
Can I move the flap by hand?
The vertical flap, no. Panasonic instructs owners not to adjust it by hand. The lateral vanes on models that have them are manually adjustable, so those are fine.
What happened to Mild Dry Cooling?
It was a feature on earlier ECONAVI era models and it does not appear in the current Z or RZ operating instructions. If your unit has it, it will be in the manual for that model. There is no published way to activate it on the current range because it is not on the current range.
Why will it not let me set 16 degrees in auto on my ducted system?
Because the ducted wired controller narrows the auto range to 17 to 27 degrees. Cooling and heating have wider ranges. Nothing is broken.
Worth doing today
Set the clock and switch it to 24 hour if you prefer, since that one is a five second hold. Cancel any on timer you did not set deliberately, because they repeat daily. And learn where eco sits on the shared button, since it is the setting that costs you nothing and saves the most.
